Fire Bricks

• Home • Products • Fire Bricks

We provide high efficiency Fire Bricks that are manufactured from the finest quality raw materials. Our Fire Clay Bricks are ideal to reduce a large amount of heat by combustion of fuels in the closed compartments. Our Refractory Fire Bricks are highly appreciated in the markets as they can control high pressure and temperature. Refractory Fire Bricks offered by us are available in various specifications as per the demands of the clients. Our Refractory Fire Bricks are widely used in the steel, glass and various other fields. We have firmly positioned ourselves as one of the key Insulating Fire Bricks Manufacturers based in India.

Attributes

Ideal to reduce large amount of heat by combustion of fuels in closed compartments
Can control high pressure and temperature
Different specifications
Made from finest quality materials

Widely Used In

Steel industries
Glass Industries
Furnaces
Machine manufacturing units

Typical Specifications :

TYPE	Al2Og (%) Min	FEZOZ (°/¤) Max.	PCE	Bulk Density Grn / cc	A.P.(%)Max	CCS 2: (Kg / Cm)2 2Min	Rul (Ta) °C Minn	PLC (%) °C Hr. Max.
			Orton Cone "C Temp. Min.
VR - 40	40	2.5	32 (1717)	2.25	25	300	1400	+1.0 at 1400 / 3
VR - 45	45	3.0	*32 +(1724)	2.25	24	350	1400	+1.0 at 1400 / 3
VR - 50	50	3.5	33 (1743)	2.40	24	400	1400	+1.0 at 1450 / 3
VR - 60	60	3.5	35 (1785)	2.50	24	400	1450	+2.0 at 1500 / 2
VR - 70	70	3.5	*36 -(1804)	2.05	23	450	1460	+3.0 at 1550 / 2
VR - 60 LF	60	2.5	36	2.8	23	400	1480	+2.0 at 1500 / 2
VR - 70 LF	70	2.2	+37	2.7	21	450	1500	+2.5 at 1550 / 2

Note : 1. The above data related to machine moulded standard bricks only.
2. Size tolerance + 1.5% or 2 mm which ever is higher.
